400mm wide x 4500mm long, with a 140mm profile thickness. Featuring a maximum capacity of 2770kg, this ramp is ideal for use as a plant ramp, digger ramp, or telehandler ramp. Please note the minimum track width is 300mm.

Custom built sizes are available on request. Price and capacity stated is for the PAIR.
Length (mm)4500
Width (mm)400
Max. Load Height (mm)1350
Weight per Ramp (kg)48
Weight per Pair (kg)96
Capacity (kg)2770
  • Customisable
  • Easy to Fit
  • European Made
  • Not for Solid Wheels
  • One Year Warranty
Ex VAT: £1,075.00 Inc VAT: £1,290.00
Built to Order

Load Height Info

Wheelbase Capacity Information

Buy With Confidence

Free Mainland UK Delivery on orders over £60

Some of our best selling medium to heavy duty plant ramp, the TRP140 Series core profile thickness is 140mm. The TRP140 Series has a width of 400mm. They feature a capacity of up to 2770kg and are ideal for use as plant ramps, for digger ramps and for tele-handlers.

On the TRP140 series the minimum width of tracks/wheels is 300mm. These Ramps are not designed for use over a 30% gradient

  • These ramps are available both with and without edges. The default is however without edges.
  • Four different connection options available, however the default connection is the Rest on Connection.
  • Custom load heights available
  • Not suitable for solid wheels found on road surfacing machines - for this type of machinery please see the industrial ramps for steel tracks.
  • Fully TÜV certified
  • Quotes for bespoke ramps can be supplied on request

TUV Certification Image

Usage Guidelines and Safety Information for these ramps can be found here

SKU TRP140/45
Wheelbase Capacity Popup Yes
Default Connection Rest On Connection
Default No Edges
Capacity (kg) 2770
Height of ramps profile (mm) 140
Length (mm) 4500
Max load height (mm) 1350
Weight per ramp (kg) 48
Weight Per Pair (kg) 96
Width (mm) 400
Minimum track width (mm) 300
One Year Warranty Yes
Customisable Yes
Easy to Fit Yes
European Made Yes
Not Solid Wheels Yes
Capacity Wheelbase 1000mm (kg 2375
Capacity Wheelbase 1250mm (kg) 2560
Capacity Wheelbase 1500mm (kg) 2770
