Profile Height up to 230mm

•

•

•

•

•

Our vehicle and loading ramps between the heights 160mm and 230mm feature four different sizes: 160mm, 170mm, 185mm, 200mm and 230mm.

TRP160 Series core profile thickness is 160mm, two widths are available: 480mm and the extra wide 510mm. They feature a capacity of up to 9000kg and are ideal for use as car ramps or lightweight plant ramps.

TRP170 Series core profile thickness is 170mm, available with a width of 510mm. They feature a capacity of up to 10.000kg and are ideal for use as plant ramps and mini digger ramps. See vehicle ramps for a full list of features and options.

TRP186 Series core profile thickness is 185mm, available with a width of 510mm. They feature a capacity of up to 12000kg and are ideal for use as plant ramps and mini digger ramps. See vehicle ramps for a full list of features and options.

TRP201 Series core profile thickness is 200mm, available with a width of 580mm. They feature a capacity of up to 14000kg and are ideal for use as plant ramps, for digger ramps and for tele-handlers.

TRP231 Series core profile thickness is 230mm, available with a width of 580mm. They feature a capacity of up to 16000kg and are ideal for use as plant ramps, for digger ramps and for tele-handlers.

Nylon grab handles are available to increase the safe manual handling of the heavy duty ramps, please contact us for a custom quote.

Not suitable for solid wheels found on road surfacing machines - for this type of machinery please see the industrial ramps for steel tracks.
