Aluminium Loading Ramps (5000x360x1070kg)

360mm wide x 5000mm long, with a 100mm profile thickness. Featuring a maximum capacity of 1070kg, this ramp is ideal for use as a car ramp or lightweight plant ramp. Please note the minimum track width is 200mm. Custom built sizes are available on request.

Price and capacity stated is for the PAIR.

  • Connection Options
  • Customisable
  • Easy to Fit
  • European Made
  • Not for Solid Wheels
  • One Year Warranty
Description

The TRP101 Series core profile thickness is 100mm and have a width of 360mm. They feature a capacity of up to 1070kg and are ideal for use as car ramps or lightweight plant ramps. The TRP101 Series has a minimum width of tracks/wheels is 200mm.

These ramps are designed for use at a gradient of 30%.

  • These ramps are available both with and without edges. The default is however without edges
  • Four different connection options available, however the default connection is the rest on connection with a pin which is a popular choice for flatbed vehicles and tipper trucks. For beaver tail trailers, a hook connection is normally recommended
  • Custom load heights available
  • All pictures shown are for illustration purpose only. Actual product may vary due to product enhancement
  • Not suitable for solid wheels found on road surfacing machines - for this type of machinery please see the industrial ramps for steel tracks
  • Please note, the stated maximum weight capacities are only valid for vehicles where the weight is equally distributed – for vehicles where this is not the case, please contact us directly for assistance.
  • Quotes for bespoke ramps can be supplied on request
  • Fully TÜV certified

TUV Certification Image

Usage guidelines and safety information for our full vehicle ramp range can be found here.


Details
SKUTRP101/50
Default ConnectionRest On Connection
Capacity (kg)1070
Height of Ramps Profile (mm)100
Length (mm)5000
Max Load Height (mm)1500
Min. Load Height (mm)1350
Weight per Ramp (kg)31
Weight Per Pair (kg) 62
Width (mm)360
Minimum Track Width (mm)200
Maximum Track Width (mm)280
One Year WarrantyYes
Connection Options AvailableYes
CustomisableYes
Easy to FitYes
European MadeYes
Not Solid WheelsYes
Capacity Wheelbase 1000mm (kg)940
Capacity Wheelbase 1250mm (kg)1000
Capacity Wheelbase 1500mm (kg)1070
