Aluminium Loading Ramps (4000x300x1000kg)

300mm wide x 4000mm long, with an 75mm profile thickness. Featuring a maximum capacity of 1000kg, this ramp is ideal for use as a car ramp or lightweight plant ramp. Please note the minimum track width is 150mm.

Plant Ramps FAQ's

Length (mm)4000
Width (mm)300
Max. Load Height (mm)1200
Weight Per Ramp (kg)22,5
Weight Per Pair (kg)45
Capacity (kg)1000
  • Connection Options
  • Customisable
  • Easy to Fit
  • European Made
  • Not for Solid Wheels
  • One Year Warranty
£1,020.00 £850.00
SKU
TRP74/40
Built to Order



Description

The TRP74 Series has a core profile thickness is 75mm and a width of 300mm. On the TRP74 Series the minimum width of tracks/wheels is 150mm.


They feature a capacity of up to 1000kg and are ideal for use as car ramps or lightweight plant ramps.

Designed for a maximum gradient of 30%

  • These ramps are available both with and without edges, the default is however without edges.
  • Four different connection options available, however the default connection is the rest on connection
  • Custom load heights available
  • All pictures shown are for illustration purpose only. Actual product may vary due to product enhancement
  • Quotes for bespoke ramps can be supplied on request
  • Not suitable for solid wheels found on road surfacing machines - for this type of machinery please see the industrial ramps for steel tracks
  • Fully TÜV certified

TUV Certification Image

Usage Guidelines and Safety Information for these ramps can be found here

Details
SKU TRP74/40
Default Connection Rest On Connection
Capacity (kg) 1000
Height of Ramps Profile (mm) 75
Length (mm) 4000
Max Load Height (mm) 1200
Min. Load Height (mm) 1050
Weight per Ramp (kg) 22,5
Weight Per Pair (kg) 45
Width (mm) 300
Minimum Track Width (mm) 150
Maximum Track Width (mm) 220
One Year Warranty Yes
Connection Options Available Yes
Customisable Yes
Easy to Fit Yes
European Made Yes
Not Solid Wheels Yes
Capacity Wheelbase 1000mm (kg) 830
Capacity Wheelbase 1250mm (kg) 910
Capacity Wheelbase 1500mm (kg) 1000
