Aluminium Loading Ramps (3000x300x2330kg)

300mm wide x 3000mm long, with a 75mm profile thickness. Featuring a maximum capacity of 2330kg, this ramp is ideal on car transporters and trailers. Please note the minimum track width is 150mm. Price and capacity stated is for the PAIR.

Plant Ramps FAQ's

Length (mm)3000
Width (mm)300
Max. Load Height (mm)900
Weight Per Ramp (kg)19.5
Weight Per Pair (kg)39
Capacity (kg)2330
  • Connection Options
  • Customisable
  • Easy to Fit
  • European Made
  • Not for Solid Wheels
  • One Year Warranty
£864.00 £720.00
SKU
TRP76/30
In Stock



Description

The TRP76 Series has a core profile thickness of 75mm and a width of 300mm. On the TRP76 Series the minimum width of tracks/wheels is 150mm.

They feature a capacity of up to 2330kg and are ideal for use on car transporters and trailers.

Designed for a maximum gradient of 30%

  • These ramps are available both with and without edges, the default is however without edges
  • Four different connection options available, however the default connection is the rest on connection
  • Custom load heights available
  • Quotes for bespoke ramps can be supplied on request
  • Not suitable for solid wheels found on road surfacing machines - for this type of machinery please see the industrial ramps for steel tracks
  • Fully TÜV certified

TUV Certification Image

Usage Guidelines and Safety Information for these ramps can be found here

Details
SKU TRP76/30
Default Connection Rest On Connection
Capacity (kg) 2330
Height of Ramps Profile (mm) 75
Length (mm) 3000
Max Load Height (mm) 900
Min. Load Height (mm) 750
Weight per Ramp (kg) 19.5
Weight Per Pair (kg) 39
Width (mm) 300
Minimum Track Width (mm) 150
Maximum Track Width (mm) 220
One Year Warranty Yes
Connection Options Available Yes
Customisable Yes
Easy to Fit Yes
European Made Yes
Not Solid Wheels Yes
Capacity Wheelbase 1000mm (kg) 1750
Capacity Wheelbase 1250mm (kg) 2000
Capacity Wheelbase 1500mm (kg) 2330
