Aluminium Loading Ramps (2500x550x20000kg)

550mm wide x 2500mm long, with a 230mm profile thickness. Featuring a maximum capacity of 20,000kg, this is one of our heaviest duty ramps and is ideal for use as an industrial plant ramp or heavy duty commercial ramp. Please note the minimum track width is 450mm. Custom built sizes are available on request. Price and capacity stated is for the PAIR.

Plant Ramps FAQ's

Length (mm)2500
Width (mm)550
Max. Load Height (mm)750
Weight Per Ramp (kg)58
Weight Per Pair (kg)116
Capacity (kg)20000

Got a question?

Product: Aluminium Loading Ramps (2500x550x20000kg)

  • Connection Options
  • Customisable
  • Easy to Fit
  • European Made
  • Not for Solid Wheels
  • One Year Warranty
£1,650.00 £1,375.00
Built to Order
Talk to The Ramp People's sales team

One of our heaviest duty ramps from our standard range. The TRP230/25TRP Series core profile thickness is 230mm.
At 550mm these ramps are over half a metre wide and feature a capacity of up to 20,000kg and are ideal for use as industrial plant ramps and as heavy duty as commercial ramps.

On the TRP230/25TRP series the minimum width of tracks/wheels is 450mm.

  • These ramps are available both with and without edgesconnection
  • Custom load heights available
  • Not suitable for solid wheels found on road surfacing machines - for this type of machinery please see the industrial ramps for steel tracks
  • Fully TÜV certified
  • Quotes for bespoke ramps can be supplied on request
  • All pictures shown are for illustration purpose only. Actual product may vary due to product enhancement

TUV Certification Image

Usage Guidelines and Safety Information for these ramps can be found here

Default Connection Rest On Connection
Capacity (kg) 20000
Height of Ramps Profile (mm) 230
Length (mm) 2500
Min Load Height (mm) 600
Weight per Ramp (kg) 58
Weight Per Pair (kg) 116
Width (mm) 550
Minimum Track Width (mm) 400
One Year Warranty Yes
Connection Options Available Yes
Customisable Yes
Easy to Fit Yes
European Made Yes
Not Solid Wheels Yes
Capacity Wheelbase 1000mm (kg) 20,000
Capacity Wheelbase 1500mm (kg) 20,000
Capacity Wheelbase 2000mm (kg) 20,000
