Aluminium Loading Ramps (2500x580x14000kg)

580mm wide x 2500mm long, with a 200mm profile thickness. Featuring a maximum capacity of 14000kg, this is one of our heaviest duty ramps and is ideal for use as an industrial plant ramp or heavy duty commercial ramp. Please note the minimum track width is 300mm. Custom built sizes are available on request. Price and capacity stated is for the PAIR.

Plant Ramps FAQ's

Length (mm)2500
Width (mm)580
Max. Load Height (mm)750
Weight Per Ramp (kg)51
Weight Per Pair (kg)102
Capacity (kg)14000
Product Inquiry
  • Connection Options
  • Customisable
  • Easy to Fit
  • European Made
  • Not for Solid Wheels
  • One Year Warranty
£1,848.00 £1,540.00
SKU
TRP201/25
Built to Order
Talk to The Ramp People's sales team

The TRP201 Series core profile thickness is 200mm.
At 580mm these ramps are over half a metre wide, feature a capacity of up to 14000kg and are ideal for use as industrial plant ramps and as heavy duty commercial ramps.

On the TRP201 series the minimum width of tracks/wheels is 300mm.

  • These ramps are available both with and without edges. The default is however without edges.
  • Four different connection options
  • Custom load heights available
  • All pictures shown are for illustration purpose only. Actual product may vary due to product enhancement
  • Not suitable for solid wheels found on road surfacing machines - for this type of machinery please see the industrial ramps for steel tracks.
  • Quotes for bespoke ramps can be supplied on request
  • Fully TÜV certified

TUV Certification Image

Usage Guidelines and Safety Information for these ramps can be found here

SKU TRP201/25
Default Connection Rest On Connection
Capacity (kg) 14000
Height of Ramps Profile (mm) 200
Length (mm) 2500
Max Load Height (mm) 750
Min. Load Height (mm) 600
Weight per Ramp (kg) 51
Weight Per Pair (kg) 102
Width (mm) 580
Minimum Track Width (mm) 300
Maximum Track Width (mm) 480
One Year Warranty Yes
Connection Options Available Yes
Customisable Yes
Easy to Fit Yes
European Made Yes
Not Solid Wheels Yes
Capacity Wheelbase 1000mm (kg) 14000
Capacity Wheelbase 1500mm (kg) 14000
Capacity Wheelbase 2000mm (kg) 14000
